“ICON2000”
instruction and operating manual
Section 618/2 chapt. E
Section 618/2
Ain / Aout card
This optional card is used in place of the Terminal Board Adaptor (TBA) card when an
analogue 4-20mA input and output signal is requested. This card cannot be used in the
actuators with terminal board series ICON2000 v0 (see chap.E, par 7, “Operating the
ICON2000 for the first time”).
Bottom view
of base card
Terminal Board
Adaptor card
(TBA)
9. Base card of the ICON2000 v4
