9. Data exchanged during parameterization
The following data are sent to the ICON2000v4_DPV1 interface:
Byte
Name
Type
Range
Default
EU
0
Reserved DP V1
1 byte
_
_
_
1
Reserved DP V1
1 byte
_
_
_
2
Reserved DP V1
1 byte
_
_
_
3
Storage Format
1 byte
0
1
LSB first
LSB first
MSB first
4
Fail Safe Action
1 byte
0
1
2
3
4
Off
Off
Close
Open
Stayput
Go to position
5
Delay before initiating safe oper.
1 byte
0-255
4
sec
6
Safe Position
1 byte
0-100
50
%
7
Timer Open direction – status
1 byte
0
1
0ff
Off
On
8
Timer Open direction – on time
1 byte
2-200
2
sec
9
Timer Open direction – off time
1 byte
1-200
2
sec
10
Timer Open direction – start position
1 byte
0-100
0
%
11
Timer Open direction – stop position
1 byte
0-100
100
%
12
Timer Close direction – status
1 byte
0
1
Off
Off
On
13
Timer Close direction – on time
1 byte
2-200
2
sec
14
Timer Close direction – off time
1 byte
1-200
2
sec
15
Timer Close direction – start position
1 byte
0-100
100
%
16
Timer Close direction – stop position
1 byte
0-100
0
%
17
Reserved
1 byte
_
_
_
18
Dead band
1 byte
1-255
10
tenth of %
19
Motion inhibit
1 byte
1-255
6
sec
It should be noted that every time that PROFIBUS communication is established, the
parameterization string will be sent to the device writing the parameters to the set up values. The
values in parameterization string shall be modified at the Master station.
Byte 0-2 Reserved for DPV1
Byte 3 Storage Format
It defines the format of the variables that are transmitted on 2 or 4 bytes. The setting of
this parameter affects the format of the following data:
Output Data: (if Module 2 is selected)
Position Request.
Input Data: (if Module 2 is selected)
Actuator Position, Output Torque
General Maintenance Info: Slot 2 Index 0
Actuator Position, Output Torque, Opening Time, Closing Time,
Contactor Cycles, Motor Run Time, Time Without Power, Utilisation
Rate
Recent Maintenance Info: Slot 2 Index 1
Recent Contactor Cycles, Recent Motor Run Time, Recent Time
Without Power, Recent Utilisation Rate
Value: 0: LSB byte is transmitted first (default setting)
1: MSB byte is transmitted first
Byte 4 Fail Safe Action
