BIFFI ICON 2000 - Entering the View Mode

Valve data
This menu includes a series of data relevant to the valve. The valve manufacturer and the
end user should enter the data.
List of routines:
 tag name (max 28 characters)  serial number (max 28 characters)
 manufacturer (max 28 characters)  break CL torque (max 28 characters)
 break OP torque (max 28 characters)  max stem thrust (max 28 characters)
 flange type (max 28 characters)
Maintenance
This menu includes all diagnostic and historic data which can help the operator in case of
failure or during maintenance operations. The Maintenance menu also includes the "Set new
password" routine.
List of routines:
The parameters appear on the alphanumeric display in the same order both in view and
set-up mode. At the end of each routine the program will automatically return to the
beginning of the routine, and the operator can choose to either re-enter (by pressing YES) or
to move on to a next routine (by pressing NO).
3. Entering the view mode
The existing actuator configuration should be checked before commissioning. The
parameters are configured in factory according to a standard setting, or to customer
requirements. In view mode, no password is requested, but no change of parameters can
be made.
• Ensure the electrical main power is applied.
• Move the 3-position selector to OFF and then simultaneously press OPEN/YES and STOP.
• The display shows the present language. Press YES to confirm or NO to scroll the list of
available languages. Press YES to select a new language. Press YES to confirm.
• Press NO to scroll the list of available menus (actuator set-up, nameplate, valve data,
maintenance) and then press YES to select the desired menu.
• Press NO to scroll the list of available routines and press YES to select the routine where
the parameter to be viewed is located.
• Press NO to scroll the list of parameters and press YES to view the value.
SET-UP MODE
 set new password
 clear alarm log
 set torque profile reference
 set torque curve reference
 clear recent data log
 set maintenance date
 set data logger
VIEW MODE
 alarm log
 torque profile
 torque curve
 operation log
 maintenance date
 data logger
