“ICON2000”
instruction and operating manual
Section 618/2 chapt. I
Section 618/2
Configuration procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language and enter the password according to the instructions (see “Entering the
set-up mode”). When the message displayed is “SET-UP MODE OK?” press YES. Press
NO to scroll the list of available menus and then press YES to select Maintenance menu.
• Press NO to scroll the list of available routines and then press YES to select Set password.
Press YES again to select Enter new password.
• Enter the new password one digit at a time. Press YES if the digit is correct, press NO to
scroll the list of available characters and then press YES to select. Enter 4 digits. When the
display shows the message Password changed the old password is no longer valid.
3.2 CLEAR ALARM LOG
Clear procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language and enter the password according to the instructions (see “Entering the set-up
mode”). When the message displayed is “SET-UP MODE OK?” press YES. Press NO to
scroll the list of available menus and then press YES to select the Maintenance menu.
• Press NO to scroll the list of available routines and then press YES to select clear alarm
log.
• Press YES to clear alarm log.
3.3 SET TORQUE REFERENCE
The set torque profile reference routine allows to transfer the last torque profile to the
reference profile registers. The old reference data are lost and the new ones are used as a
new reference torque profile.
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language and enter the password according to the instructions (see “Entering the
set-up mode”). When the message displayed is “SET-UP MODE OK?” press YES. Press
NO to scroll the list of available menus and then press YES to select maintenance menu.
• Press NO to scroll the list of available routines and then press YES to select Set torque
reference.
• Press YES to update the torque reference data.
3.4 SET CURVE REFERENCE
The “set curve reference” routine allows to select 1 off 100 opening and closing torque
curves in the memory of the ICON2000 and to transfer them to the torque curve reference
registers. The old reference data are lost and the new ones will be the new torque curves
reference (see VIEW mode, Maintenance, Torque Curve, chap L ).
Configuration procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language and then enter the password according to the instructions (see “Entering the
set-up mode”). When the message displayed is “SET-UP MODE OK?” press YES. Press
NO to scroll the list of available menus and then press YES to select maintenance menu.
• Press NO to scroll the list of available routines and then press YES to select Set curve
reference.
• Press NO to scroll the list and then press YES to select the desired curves (in opening and
closing).
• Press YES to update the torque curve reference.
