“ICON2000”
instruction and operating manual
Section 618/2 chapt. I
Section 618/2
Set-up procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language and then enter the password according to the instructions (see “Entering the
set-up mode”). When the message displayed is “SET-UP MODE OK?” press YES. Press
YES to select the actuator set-up menu, press NO and then press YES to select the
torque set-up routine.
• Press YES if the opening torque limit is correct, press NO to scroll the list of available
values. Press YES when the value is correct.
• Press YES if the closing torque limit is correct, press NO to scroll the list of available
values. Press YES when the value is correct.
1.3 ESD CONTROL
An ESD signal can be connected to the actuator to override any existing command and
drive the valve to a predetermined position. The ESD control is not self-maintained: the ESD
action is only performed if the relevant input is active. The ESD control is active when the
3-position selector is in REMOTE and no alarm is present.
Warning: The user may select ESD to override the situations indicated
by (*). If these situations occur and if “ESD > ...” is configured,
the actuator may be damaged. Therefore, selecting
“ESD > ...” will invalidate the warranty.
Function "ESD priority" allows the ESD command to override the following additional
situations: (*) motor thermostat alarm, (*) torque limit tripped, (*) local stop pressed, 3-position
selector in local, 2-speed timer, (*) 3-position selector in OFF
Configuration procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language and then enter the password according to the instructions (see “Entering the
set-up mode”). When the message displayed is “SET-UP MODE OK?” press YES. Press
YES to select actuator set-up menu, press NO to scroll the list of available routines and
then press YES to select ESD set-up.
• Press YES if the ESD action is correct, or press NO to scroll the list of available options
(off, open, close, stay-put, go to position xx %). Press YES to select the desired option.
• Press either YES or NO to select the signal type (present, absent)
• Press YES to change ESD priority with reference to the following signals or status:
• (*) motor thermostat alarm. Choosing ESD > THERMOSTAT, the ESD action will be
carried out also in case of motor over-heating. Vice-versa, if ESD < THERMOSTAT was
chosen, the ESD action will not be done in case of motor over-heating.
• (*) torque limit tripped. Choosing ESD > TORQUE LIMIT, the ESD action will be carried out
also in case of torque alarm. Vice-versa, if ESD < TORQUE LIMIT was chosen, the ESD
action will not be done in case of torque alarm.
• (*) local stop pressed. Choosing ESD > LOCAL STOP, the ESD action will override the
local STOP signal. Vice-versa, if ESD < LOCAL STOP was chosen, the ESD action will not
be performed if the local STOP push-button is pressed.
