BL-CB33-0115 - 03-01-2018 12-15
DRIVE ASSEMBLY - Used between serial # S2410420 and 325130600
Pos. Part Number Description
Qty.
Reqd.
Notes
1 1280-210048-00 MOTOR 1
2 1280-210000-00 BRAKE ASSEMBLY 1
3 0000-000516-00 SCREW M12×40 6
4 0000-000060-00 LOCKWASHER Ø12 6
5 0000-000373-00 FLATWASHER Ø12 6
6 1280-520009-10 SWITCH WIRE HARNESSII 1
7 0000-000006-00 SCREW M6×30 1
8 1280-210053-10 ELASTIC COLLAR 1
9 0000-000322-00 SCREW M8×25 3
10 0000-000159-00 LOCKWASHER Ø8 7
11 CK10-240000-20 STEERING MOTOR 1
12 1280-210042-10 MOTOR GEAR 1
13 2415-220000-10 GEAR CASE ASSEMBLY 1
14 2415-230000-10 DRIVE WHEEL 1
15 0000-000283-00 BOLT M10×35 6
16 0000-000063-00 LOCKWASHER Ø10 6
17 0000-001281-00 SCREW M8×75 4
18 0000-000176-00 FLATWASHER Ø8 4
19 CK10-240001-20 KB-SENSOR, STEERING MOTOR 1
