Vital Signs Monitor User’s Manual
Chapter 1-4
1.2.3 Rear View
Fig.1-3
1. Temp connector
2. Grounding terminal
3. AC power input connector
Connect to USB device, such as keyboard and mouse.
4. Serial port
5. Wired network connector
Standard RJ45 socket, it is used for connection with the central monitoring system
provided by manufacturer.
6. USB socket
7. Nurse call connector
8. Fan and horn orifice
Note
The wired network connector is used for connection with the central
monitoring system provided by manufacturer.
