Vital Signs Monitor User’s Manual
Chapter 1-3
Press this button to turn on the monitor after AC power is connected or the
Press and hold it for 2 seconds to turn the monitor off.
13. Power indicating lamp
It is a LED that lights green and orange, the status of the LED is specified as
Green: When the AC mains is connected.
Orange: When the AC mains is not connected and monitor is powered by
Off: When the AC mains is not connected.
14. Battery charging indicating lamp
Light up: When the battery is being charged.
Off: When the battery is fully charged or no battery in monitor.
1.2.2 Side View
Left side:
Fig.1-2
