Vital Signs Monitor User’s Manual
Chapter 2-5
Symbol
Symbol Note
Dangerous voltage
Equipotential grounding
100V-240V~
Alternating current input range: 100V-240V
USB socket
Network connector
Nurse call connector
Manufacture date
Manufacturer
SN
Serial number
IPX1
Degree of protection against ingress of liquid
Hospital Only
Symbol marked on a tag attached to the supply cord of the monitor to
warn that the supply cord should be connected to the sockets which are
Hospital Only to achieve grounding reliability.
SpO
2
Short for “Pulse Oxygen Saturation”
NIBP
Short for “Non-invasive Blood Pressure”
CO
2
Short for “Carbon dioxide”
Temp
Short for “Temperature”
Symbol for the marking of electrical and electronics devices according to
Directive 2002/96/EC.
