30 | Chapter 2: Installation
BioTek Instruments, Inc.
4. While holding the carrier, carefully turn the instrument over and hook the
shipping straps over the post (
Figure 9).
5. Using a slotted screwdriver, remove the four top cover mounting screws.
6. Lift the instrument off the cover and turn it over.
Figure 9: Hooking the shipping straps over the post
Post
Mounting screws
Top cover
Shipping
straps
