Define (Method, Map, Formula and Curve) | 47
ELx800 Operator’s Manual
Define (Method, Map, Formula and Curve)
The DEFINE screen allows you to edit the Method, Map, Formula, or Curve Fit
parameters for the currently selected assay.
D E F I N E :
M E T H O D MAP FORMULA CU R V E
Press the
SOFT KEY beneath the displayed option to access the following functions:
• METHOD: Specify the wavelength type, wavelength, filter(s), and plate
geometry.
• MAP: Specify mapping information.
• FORMULA: Access the formula entry screens.
• CURVE FIT: Specify curve-fit options.
Defining METHOD
Defining a method includes selecting:
• Single or dual wavelength
• Filter(s)
• Plate geometry

The options appear on the display in the order that they
were programmed in the assay. If the assay contains a closed
variable (i.e., an element of the assay definition that you
cannot access or modify), the entry screen is skipped.
