Repackaging and Shipping the ELx800 | 31
ELx800 Operator’s Manual
7. Install the shipping block: place the groove in the shipping block over the
shaft and use a Phillips screwdriver to attach the two mounting screws
(
Figure 10).
Figure 10: Installing the shipping block
Shipping
block
Shaft
