ELx800 Front Panel | 39
ELx800 Operator’s Manual
The keypad has four SOFT KEYS, one below each selectable menu
option. Press a
SOFT KEY to make a selection. For example, from the
Main Menu, press the leftmost
SOFT KEY to select READ, the
rightmost to select UTIL.
Exit the current screen and return to the
Main Menu. Pressing Main
Menu while defining or modifying an assay automatically saves the
current settings.
Cycle through available options within a screen. For example, press
Options within the Select Assay Number screen to cycle through
the names of the onboard assays.
Pressing
ENTER generally saves the current screen settings and
advances to the next screen in a series.
Pressing
Previous Screen generally saves the current screen settings
and returns control to the screen most previously viewed.
Press
CLEAR to reset a numeric value to 0, or to clear all characters
when editing an assay name.
Tip: Press Shift + Clear at the Map
Generation
screen to “clear” a previously defined manual map.
Move the cursor to the left in data-entry screens.
Move the cursor to the right in data-entry screens.
Initiate a plate read.
Halt the read currently in progress.
7G
Press a number to enter it in a data-entry screen.
Shift + 7G
Press Shift + a number (for example, Shift + 7G) to enter the
letter, then press
Options to advance through the alphabet.
Main
Menu
Options
ENTER
Previous
Screen
CLEAR
READ
STOP
