BK Precision 2650 User Manual

–3–
2.Specifications
2.1 Performances
·Frequency section
2650/2652 2658
Frequency range 50kHz to 3.3GHz 50kHz to 8.5GHz
Frequency
range
Frequency
band
Harmonic
order
50k～3.5GHz Base band 1
3.3G～6.3GHz Band 1- 1
―――
6.1G～8.5GHz Band 1+ 1
Center frequency
Setting
resolution
100kHz
Allows Rotary encoder, numeric key and function key
Accuracy within ±(30+20T)kHz±1dot
@frequency span: 200kHz to 10MHz,
RBW: 30kHz, 23±5°C
within ±(100+700T)kHz±1dot
@frequency span: 20MHz to 3.3GHz,
RBW: 100kHz, 23±5°C
T: Sweep time(s)
within ±(30+20T)kHz±1dot
@frequency span: 200kHz to 10MHz,
RBW: 30kHz, 23±5°C
within ±(60+300T)kHz±1dot
@frequency span: 20MHz to 8.5GHz,
RBW: 100kHz, 23±5°C
T: Sweep time(s)
RBW
frequency
error
within ±6% of RBW@ RBW: 3kHz, 30kHz
within ±30% of RBW@ RBW: 100kHz to 3MHz
Frequency span
Setting range 0Hz(zero span),
200kHz to 2GHz(1-2-5step) and
3.3GHz
0Hz(zero span), 200kHz to 5GHz
(1-2-5step) and 8.5GHz(full span)
Accuracy within ±3%±20TkHz±1dot
@frequency span: 200kHz to 10MHz,
23±5°C
within ±3%±200TkHz±1dot
@frequency span: 20MHz to 3.3GHz,
23±°C T: Sweep time(s)
within ±3%±20TkHz±1dot
@frequency span: 200kHz to 10MHz,
23±5°C
within ±3%±200TkHz±1dot
@frequency span: 20MHz to 8.5GHz,
23±5°C T: Sweep time(s)
Display resolution Frequency span/250
Frequency span/1000 (only the measurement by RS-232C
Display dot number 251dots, 1001dots (only the measurement by RS-232C communication)
(The unit displays data in 251 horizontal dots, but it internally captures the trace in
1001 dots)
Resolution bandwidth 3dB bandwidth @9kHz, 120kHz
