32–
18. Save/Load <SAVE/LOAD>
18.1 Save/Load (2650/2652)
Press to switch over to the function screen shown below:
18.1.1 Setting the location to store the trace
1. Pressing allows you to set the number of location to store the trace.
2. Use to set the number of location.
00 01 02 03 04 ··· 98 99
* The part of TRACE become inverted display after it is selected.
18.1.2 Setting the location to store the parameter
1. Pressing allows you to set the number of location to store the parameter.
2. Use to set the number of location.
00 01 02 03 04 ··· 98 99
* The part of PARAM become inverted display after it is selected.
18.1.3 Saving the data
1. Press to save the data at the set number.
* This saves the trace when TRACE is selected, or the setting parameters when PARAM is selected.
* “
*
” is displayed on the right end of the number of location place at which data is saved.
* It can be overwritten, too
18.1.4 Loading the data
1. Press to read out the data at the set number.
* This reads out the trace when TRACE is selected. The setting parameter of the loaded trace is
displayed in the loaded trace information display area.
(Refer to “4. Description of Display” for details)
* This reads out the setting parameters when PARAM is selected.
TRACE PARAM EXECUTE PRE
00 00 SAVE LOAD DEL SET
F2
F3
F4
F1
SAVE/LOA
F1 F2 F3
F4
F5
F6
To Next Page
