34–
18.2 Save/Load (2658)
Press to switch over to the function screen shown below:
18.2.1 Saving the data
1. Press to move to a save menu.
2. Operating
or chooses objects (trace or parameter).
3. Use to set the number of location.
00 01 02 03 04 ··· 98 99
4. Press to save the data.
* This saves the trace when TRACE is selected, or the setting parameters when PARAM is selected.
* “
*
” is displayed on the right end of the number of location place at which data is saved.
* It can be overwritten, too
18.2.2 Loading the data
1. Press to move to a load menu.
2. Operating
or chooses objects (trace or parameter).
3. Use to set the number of location.
00 01 02 03 04 ··· 98 99
4. Press to load the data.
* This reads out the trace when TRACE is selected. The setting parameter of the loaded trace is
displayed in the loaded trace information display area.
(Refer to “4. Description of Display” for details)
* This reads out the setting parameters when PARAM is selected.
* When you load a trace, the current trace disappears, the HOLD state is set, and the loaded trace
is displayed. For the loaded trace, you can use the marker, but cannot use a measuring function.
ＭＯＤＥ ＳＥＬＥＣＴ ＤＩＳＰ ＰＲＥ
ＳＡＶＥ ＬＯＡＤ ＣＬＥＡＲ ＣＬＥＡＲ ＳＥＴ
F2
F1
SAVE/LOA
Ｆ１ Ｆ２ Ｆ３
Ｆ４
Ｆ５
Ｆ６
F1 F2
F1 F2
F3
F3
