26. Basis Performance Test
To keep the quality of the unit, regular performance testing is recommended. This section describes
a method and specification of basic performance testing. If a problem is found in the results of basic
performance testing, or formal testing is needed, please contact the dealership where you purchased the
product, or contact us.
[Connection diagram]
26.1 Frequency characteristics
Adjust the output level of the spectrum analyzer calibration unit (thereafter, “calibration unit”) so that the
displayed power value is -15dBm at each frequency for this unit, and measure the absolute value with a
receiver for calibration (microwave power meter, etc.).
Setting of 2650/2652/2658
Center
frequency
Frequency
span
RBW *1
Specifications Measurement value Judgment
50kHz 200kHz 10kHz Within Reference±2.6dB±1dot
100kHz 200kHz 30kHz Within Reference±2.6dB±1dot
1MHz 2MHz 100kHz Within Reference±1.6dB±1dot
10MHz 10MHz 3MHz Within Reference±1.0dB±1dot
100MHz 10MHz 3MHz Reference
1GHz 10MHz 3MHz Within Reference±1.0dB±1dot
2GHz 10MHz 3MHz Within Reference±1.0dB±1dot
3.3GHz 10MHz 3MHz Within Reference±1.0dB±1dot
6.2GHz *2 10MHz 3MHz Within Reference±1.0dB±1dot
8.5GHz *2 10MHz 3MHz Within Reference±1.0dB±1dot
*1 RBW switching error is included at RBW other than 3MHz. *2 2658 only
· Setting of 2650/2652/2658 · Setting of calibration unit
Reference level
:
-15dBm
Frequency
:
Same as a center frequency of
VBW
:
1MHz
2650/2652/2658.
Sweep time
:
1s
Detection mode
:
SMPL
Output power
:
Display scale
:
2dB/div
Adjust the power indication of
2650/2652/2658 to
-15dBm.
Spectrum analyzer calibration unit
2650/2652/2658
Receiver for calibration
