17–
← Please ground and
use it surely.
6. Preparing for Operation
6.1 Stand
Utilize the stand on the back to use the screen in an easier-to-see angle on the desk.
6.2 Connection to power supply
The BC 2650 AC adapter is both for the use with AC power supply and for charging the BP 2650 built-in
battery. (Charge is started automatically if AC adapter is connected)
Connect the adapter as in the figure below and connect the AC plug to the power line (100-240 VAC,
50/60 Hz). For static electricity protection, ground the unit by connecting the three cores if possible. Not
grounding the unit can damage it and the object measured. Do not use an AC adapter other than the BC
2650 supplied with the unit. Using an AC adapter other than the BC 2650 may cause damage to the unit.
Please confirm that the GND of the power supply is grounded also.
* If the voltage of a battery becomes low at the time of battery operation, it will be displayed on a screen as
“Low Batt”, and a buzzer will sound (it sounds, even if it is set up so that a buzzer may not sound), and a
power supply will be shut off within several minutes. At that time, since the switch is the position of “ON”,
please push once and return to the position of “OFF”. If it is with the position of “ON” after a power supply
is shut off, it discharges inside, will be in electric overdischarge state, and becomes the cause of
contracting the life of a battery. Please take care.
AC adapter
BC 2650
Battery full charge time: approx.8hours
Battery operate time: the longest 110min. (back light OFF)
* When it is not operated at normal temperature,
and setting parameters is the initialization.
Connect to 100 to 240 VAC, 50/60Hz
To Next Page
