7. Center Frequency <FREQ>
Press to switch over to the function screen shown below:
* Center frequency can be set between 0 to 3.3GHz.(2650/2652)
* Center frequency can be set between 0 to 8.5GHz.(2658)
* Center frequency may shift for the time being (1 to 10 sec.), after changing a setting.
7.1 Setting with the step keys ([F1], [F2])
1. Each time is pressed, the center frequency decreases in the set step size.
2. Each time is pressed, the center frequency increases in the set step size.
3. Setting the step size:
Each time is pressed, it is set in the following order:
0.1MHz 1MHz 10MHz 100MHz
7.2 Setting with the encoder
1. When is turned, the center frequency changes in the set step size.
2. Setting the step size:
Each time is pressed, it is set in the following order:
0.1MHz 1MHz 10MHz 100MHz
7.3 Setting with the numeric keys
1. Press to enter into the numeric key input mode.
* [F5] functions as the <CLEAR> key. [F6] functions as the <BACK SPACE> key.
* In this mode, setting with [F1], [F2] or the encoder is not accepted.
2. The center frequency can be directly input according to the “Numeric Key Mapping Diagram”.
3. The value is entered by pressing a unit key, [MHz (RS232C)] or [GHz (DSPL)].
* Any figures below the resolution (100 kHz) will be discarded.
CENTER FREQ KeyST EncST SET
100M 0.1M NUM MKR
F2
F3
F4
F5
FRE
F1
F1 F2 F3
F4
F5
F6
