BK Precision 2650 User Manual

–
70–
26.4 The display accuracy of the frequency span
Adjust the frequency of the calibration equipment so that the peaks are at the positions of f
1
and f
9
, and
measure the frequencies of f
1
and f
9
. Calculate from f
1
and f
9
the display accuracy of the frequency span.
*1 2650/2652 *2 2658 only
· Setting of 2650/2652/2658 · Setting of calibration unit
Reference level
:
-15dBm Frequency
:
Adjust it to the positions of f
1
VBW
:
AUTO and f
9
.
Sweep time
:
1s Output power
:
Detection mode
:
SMPL
-15dBm
Display scale
:
2dB/div
26.5 Linearity of the amplitude axis
Adjust the level of the calibration unit so that the peak is at the top of the amplitude axis (0th div), and
regard the point set at that time as the reference. Gradually lower the output, starting from the reference,
and measure the amplitude value of 2650/2652/2658.
Setting of 2650/2652/2658
Display scales
Output of calibration unit Specifications
Measurement
value
Judgment
XdBm (adjust it to the 0th div)
Reference(-15dBm) (-15dBm)
X-10dBm
Within -25dBm±0.8dB±1dot
10dB/div
X-70dBm
Within -85dBm±1.6dB±1dot
XdBm (adjust it to the 0th div)
Reference(-15dBm) (-15dBm)
X-2dB
Within -17dBm±0.2dB±1dot
2dB/div
X-10dB
Within -25dBm±0.8dB±1dot
· Setting of 2650/2652/2658 · Setting of calibration unit
Center frequency
:
100MHz Frequency
:
100MHz
Reference level
:
-15dBm
Frequency span
:
10MHZ
RBW
:
3MHz
VBW
:
1MHz
Sweep time
:
1s
Detection mode SMPL
Setting of 2650/2652/2658
Frequency span
Center
Frequency
RBW
Specifications
f
1
Measurement
value
f
9
Measurement
value
(f
9
- f
1
)
×
1.25
Judgment
200kHz 100MHz 3kHz within ±26kHz ±1dot
10MHz 100MHz 100kHz within ±320kHz ±1dot
20MHz 100MHz 300kHz within ±0.8MHz ±1dot
200MHz 100MHz 3MHz within ±6.2MHz ±1dot
500MHz 1GHz 3MHz within ±15.2MHz ±1dot
2GHz 1GHz 3MHz within ±60.2MHz ±1dot
FULL(3.3GHz)*1 1.65GHz 3MHz within ±99.2MHz ±1dot
2GHz *2 4.8GHz within ±60.2MHz ±1dot
2GHz *2 7.4GHz within ±60.2MHz ±1dot
FULL(8.5GHz)*2 4.25GHz within ±255.2MHz ±1dot
* f
1
: 1st div from the left on the trace screen f
9
: 9th div from the left on the trace screen
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
FAX 781.665.0780 - TestEquipmentDepot.com
