–6–
Communication
Interface RS-232C
Baud rate 2,400 to 38,400bps
Hard copy Allows direct hard copy with an optional printer.
Display LCD
Backlight CFL backlight
Display
Resolution 320 (H) × 240 (V) dots
Power source
Battery Ni-MH battery (optional)
External DC source DC jack, +4.75 to +5.25VDC/4A
· Other
2650/2652/2658common
Operating temperature 0 to 50°C (Guaranteed at 23±10°C, without soft carrying case)
Operating humidity
less than 40°C/80%RH
(Guaranteed at less than 33°C /70%RH, without soft carrying case)
Storage temperature -20 to 60°C, less than 60°C/70%RH
Dimensions 162 (W) × 70 (H) × 260 (D) mm (exclude projections and stand)
Weight approx. 1.8kg (include battery), approx. 1.5kg (without battery)
*Refer to ”21.Tracking Generator Mode” for T.G. Specification
2.3 Outline
[Unit: mm]
* B&K Precision Corporation reserves the right to make changes in design, specification and other information without prior notice
.
