–5–
@frequency span: 0 to 2GHz
30ms to 30s and AUTO (1-3step)
@frequency span: full span
@frequency span: 0 to 2GHz
30ms to 30s and AUTO (1-3step)
@frequency span: 5GHz
Accuracy
within ±0.1%±1dot@ frequency span: 0
to 2GHz
within ±1.5%±1dot@ frequency span:
full span
within ±0.1%±1dot@frequency span: 0
to 5GHz
within ±2.5%±1dot@frequency span:
full span
Trigger mode AUTO(frequency span: zero span)
Detection mode Positive peak, Negative peak, Sample
· Functions
2650/2652 2658
Marker
NORM: displays frequency (7digits max) and level (4digits max) at marker point.
DELTA: displays differential frequency and level between 2 markers.
Peak search
NORM: searches a peak point within 10div. Available NEXT peak (10max).
ZONE: searches a peak point within a zone designated by center and width.
Marker moves to a peak point each sweep.
Calculation NORM, MAX HOLD, MIN HOLD, AVERAGE, OVER WRITE
MAX/MIN HOLD: 2 to 1024 times, AVERAGE: 2 to 256
Measuring
Channel power, Adjacent channel leakage power, Occupied frequency bandwidth,
Electric field strength (needs antenna), Magnetic field strength (needs optional
magnetic field probe) measurement, Frequency counter.
AUTO tuning
When pushing AUTO TUNE key, the
maximum level spectrum within 3.3GHz
bandwidth is adjusted to center, and
reference level, RBW, VBW and sweep
time are adjusted to optimum values.
When pushing AUTO TUNE key, the
maximum level spectrum within 8.5GHz
bandwidth is adjusted to center, and
reference level, RBW, VBW and sweep
time are adjusted to optimum values.
Save Saves 100 traces and 100 setups Save/
Load
Load Loads 1 trace and 1 setup
· General
2650/2652/2658common
Immunity of radiated
interference
Level display at 10V/m
Less than -35dBc (reference level: 10dBm)
Immunity to cabled
interference
Level display at
transient interference
of 4.0kV
Less than -30dBc (reference level: 10dBm)
Input connector SMA(J)
