33–
* When you load a trace, the current trace disappears, the HOLD state is set, and the loaded trace
is displayed. For the loaded trace, you can use the marker, but cannot use a measuring function.
When you press the HOLD/RUN key, the loaded and the current traces are displayed
overlapping each other.
* “
*
” is displayed on the right end of the number of location place at which data is saved.
* When you search the trace or setting parameters to be read out, repeat
···, and load the trace or setting parameters in turn.
18.1.5 Clearing the loaded trace
1. Press to clear the loaded trace that has been displayed.
18.1.6 Presetting (Initialization)
1. Press to preset the setting parameters as the Initialization shown below:
“Initialization”
Items Parameter
Center frequency 1GHz
Frequency span 20MHz
Reference level 10dBm
Offset 0.0dB
Impedance 50Ω
Sweep time 0.3s
Detection mode Positive peak mode
RBW 100kHz
VBW 10kHz
Display scale 10dB/div
F5
F
6
F4 F4
