OM-040055EB Rev. 07/10

Printed in Japan

©2007 B&K Precision Corp.

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176

FAX 781.665.0780 - TestEquipmentDepot.com

Table of Contents

Default Chapter3
- After Service3
- Table of Contents4
1 Outline8
- Product Outlines8
- Standard Accessories9
2 Specifications10
- Performances10
- Outline13
3 Description of Panel14
4 Description of Screen17
5 Function Key Menu18
- List of the Function Key Menus18
- Menu Tree19
6 Preparing for Operation24
- Stand24
- Connection to Power Supply24
- Replacing the Fuse25
- Installing the Battery25
- Soft Carrying Case25
7 Center Frequency <FREQ26
- Setting with the Step Keys26
- Setting with the Encoder26
- Setting with the Numeric Keys26
- According to the Marker Position27
8 Frequency Span <SPAN27
9 Reference Level <REFER28
- Setting the Reference Level29
- Switching Units of Amplitude Axis29
- Reference Level Setting Range for each Unit29
- Relation between the Reference Level and ATT·AMP30
- Setting the Offset Level30
10 Display Scale <SCALE31
- Setting with the Keys31
- Setting with the Encoder31
11 Resolution Bandwidth <RBW32
- MANUAL Mode32
- AUTO Mode32
- ALL AUTO Mode32
12 Video Bandwidth <VBW32
- MANUAL Mode33
- AUTO Mode33
- ALL AUTO Mode33
13 Sweep Axis · Detection Mode <SWEEP33
- ALL AUTO Mode34
- Setting the Detection Mode34
14 AUTO Tuning <AUTO TUNE34
15 Hold/Run <HOLD/RUN34
16 Calculation Function <CALC34
- NORM Mode35
- MAX HOLD Mode35
- MIN HOLD Mode35
- AVERAGE Mode35
- OVER WRITE Mode36
- SPURIOUS FREE Mode36
17 Marker · Peak Search <MKR37
- Moving the Marker37
- Setting the Peak Search <PEAK SEARCH38
- Changing the Unit of Marker Point38
18 Save/Load <SAVE/LOAD39
- Save/Load (2650/2652)39
- Save/Load (2658)41
19 Measuring Function<Meas43
- Channel Power Measurement <Ch Power44
- Adjacent Channel Leakage Power Measurement <Adj Ch Pw45
- Occupied Frequency Bandwidth Measurement <Occ BW46
- Electric Field Strength Measurement <E/F ANT47
- Magnetic Field Strength Measurement <M/F PROBE> (Optional)52
- Frequency Counter <Freq COUNT> (Factory Option)54
20 Screen Control <DSPL55
- Adjusting the Contrast55
- Switching on and off the LCD Backlight55
- Adjusting the Brightness of the LCD Backlight55
- Inverting the Display55
- Enable or Disabling the Beep55
21 Tracking Generator Mode56
- Specification Only for T.G. Function56
- Description of I/O Connector56
- Switching on and off the T.G. Function57
- Normalizing of Waveform57
22 Printing <PRINT> (Optional)58
- Hard Copy of the Screen58
23 Data Output <RS232C59
- Selecting the Trace to Transfer59
- Selecting the Communication Speed (Baud Rate)59
- Transfer the Data59
24 RS-232C Interface61
- RS-232C Specifications61
- How to Connect61
- Command Description61
- Input the Frequency67
- Writing of Original Compensation Data67
- Sample Programs69
25 PC Software (Optional)70
26 Basis Performance Test71
- Frequency Characteristics71
- Accuracy of Reference Level72
- The Display Accuracy of the Center Frequency72
- The Display Accuracy of the Frequency Span73
- Linearity of the Amplitude Axis73
