5.5 Components of the bp308
BÖHNKE + Partner can supply the following components for the con-
trol system bp308:
Landing call unit CAP-01/02
Landing call unit CIO-01
Car operation unit CLK-03
CAN data communication gateway CDG-01
CAN-Serial-Interface CSI-01
Further components from different manufacturers, such as, for
example, absolute encoders or push button units complying with the
standard CiA-417 are available and may be used .
A list of CANopen components available and their descriptions can
be accessed at www.CANopen-Lift.org.
27
Fig. 7
Printed circuit board CAP-01/02
connecting landing calls to the
CANopen bus .
Fig. 6
Illustration of the dynamic call allocation of a group controller in WinMOS®300 for the controller system
bp308
