Memory card slot for software updates, log files, and parameter
backups.
Based on these concentrated functions and the conception of decent-
ralized control, small control cabinets can be used. The standard con-
trol cabinet for the control system bp308 is 600 x 600 x 250 mm and
thus intended for lifts with limited space only.
In combination with the data remote monitoring system WinMOS®300
®300 (www.WinMOS.de) it can significantly increase the availability
of the lift. In addition, this system allows you to completely match the
service intervals to the requirements
5.2 Summary of the Functions of bp308
Controls of a single lift
Controls of a bank of 8 lifts without group computer
128 landing settings
SFS – automatic push button control
SFR – automatic push button control with landing call memory
(»Taxi control«)
1KS – 1-button collective control
1KSab – 1-button down collective control
1KSauf – 1-button up collective control
2KS – 2-button up and down collective control
Operating data logs: travels, operating hours, malfunctions, mes-
sages
Rope traction lift: pole changing, one speed, two speeds, frequency
inverter, Ward Leonard drive
Hydraulically operated lift: star-delta and direct start, valve control,
soft start, frequency inverter
Positive temperature control of drive motor, integrated
Safety circuit, integrated (230 V AC standard, 48 V DC optional)
Main contactor selection 230 V AC, integrated
Safety circuit type SMZ-04, integrated
Internal primarily clocked, stabilised and short circuit resistant
mains power pack with terminal connector to the control unit
Inputs and outputs for every standard application, integrated
Inputs and outputs expandable in steps r
Positive circuitry (24 V DC)
Outputs overload protected
Diagnostics of inputs and outputs suitable for diagnostics by LCD
or laptop
Diagnostics and configuration of the CANopen components using
the CANwizard
®
Operator guidance using a laptop with WinMOS
®
300
22 Installation Manual System »bp308« – Control System »bp308«
