Modular fire panel Topologies | en 15
Bosch Sicherheitssysteme GmbH Networking guide 07.2019 | 5.9 | F.01U.247.450
OPC-Server
Figure4.4: Ethernet loop with OPC server
4.4 Ethernet loop with OPC server to redundant panel
OPC-Server
Figure4.5: Ethernet loop with OPC server to redundant panel
4.5 Ethernet/CAN double loop
Figure4.6: Double loop of Ethernet and CAN
4.6 CAN loop with Ethernet segments
The main topology is a CAN loop. When the distance between two nodes is longer than
1000m, an FX Ethernet connection can be used to cover the distance.

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
