Bosch FPA-5000 Networking Guide

Modular fire panel Appendix | en 59
Bosch Sicherheitssysteme GmbH Networking guide 07.2019 | 5.9 | F.01U.247.450
13 Appendix
13.1 Ethernet error messages
Please note that in the event of an error, the error message plus the group error is displayed
in each instance.
Physical
address
Logical
address
Error message Description and possible cause
Group faults relating to general network malfunction
135.0.1.0 Network 1.0 General Network
Trouble
There is an incompatible version of the panel network
software. There are 2 different software versions
Group faults relating to network
135.0.6.1 Network 2.1 Duplicate IP Address An IP address has been assigned twice.
135.0.6.2 Network 2.2 IP Settings The IP configuration of the reporting panel is different
to the RPS configuration
135.0.6.3 Network 2.3 Redundancy Settings The redundancy configuration (RSTP, RSTP parameter,
dual homing or nothing) of the reporting panel is
different to the RPS configuration.
Group faults relating to Rapid Spanning Tree Protocol (RSTP)
135.0.7.1 Network 3.1 RSTP Fallback The reporting panel has switched from RSTP mode to
STP mode (compatibility mode). A STP device has
been connected to the network.
135.0.7.2 Network 3.2 RSTP Topology Change The RSTP network topology has changed. For
example, another RSTP device has been added to the
network. This message may also arise in the event of
an interruption to the line.
135.0.7.3 Network 3.3 RSTP Link Type
Point2Point
An RSTP port of the reporting panel is not in the
point-2-point status. Several RSTP devices have been
connected to an RSTP port, for example. Or another
RSTP device has been connected to the RSTP port via
a half-duplex line.
Group faults relating to network connection
135.0.5.1 Network
connection 1.0
CAN 1 Trouble Data transmission to CAN bus 1 is restricted. Possible
causes include: cable breaks, cable not connected,
cable interference.
135.0.5.2 Network
connection 2.0
CAN 2 Trouble Data transmission to CAN bus 2 is restricted. Possible
causes include: cable breaks, cable not connected,
cable interference.
135.0.5.3 Network
connection 3.0
Ethernet 1 Trouble Data transmission to Ethernet line 1 is restricted.
Possible causes include: cable breaks, cable not
connected, cable interference.

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
