Bosch FPA-5000 Networking Guide

54 en | Cabling Modular fire panel
07.2019 | 5.9 | F.01U.247.450 Networking guide Bosch Sicherheitssysteme GmbH
11.3 Remote keypad
A remote keypad must be supplied with power via an FPP‑5000 External power supply.
Connection to the network is established via 2 media converters in a PSS0002A or
USF0000A.
Notice!
Note that the FPP‑5000 External power supply and the PSF0002A (PSS0002A) must be
installed in the immediate vicinity (without intermediate space) of the remote keypad. It must
not be possible to touch the connecting cables between the components, as they are not
monitored for creeping short circuit and creeping open monitoring.
Notice!
Use only media converters to connect a Remote keypad to an Ethernet panel network.
The use of switches is not permitted for the Remote keypad.
Notice!
The functional earth of the Remote keypad must always be placed in position when
connecting the unit to an Ethernet panel network.

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
