Bosch FPA-5000 Networking Guide

Modular fire panel Table of contents | en 3
Bosch Sicherheitssysteme GmbH Networking guide 07.2019 | 5.9 | F.01U.247.450
Table of contents
1
Safety 5
1.1 Organizational measures for PC running service clients 5
1.2 Explanations of safety symbols 6
1.3 Safety notices 6
2
Introduction 7
3
System overview 8
4
Topologies 9
4.1 CAN loop 14
4.2 Ethernet loop 14
4.3 Ethernet loop with OPC server 14
4.4 Ethernet loop with OPC server to redundant panel 15
4.5 Ethernet/CAN double loop 15
4.6 CAN loop with Ethernet segments 15
4.7 Ethernet backbone with sub-loops (Ethernet/CAN) 16
4.8 Connecting Ethernet loops 17
5
Ethernet network 19
5.1 Protocols 19
5.2 Network diameter 20
5.3 Cables used 22
5.4 Creating or modifying an Ethernet network 23
6
CAN network 24
6.1 Creating or modifying a CAN network 25
7
Ethernet and CAN networking pattern 26
7.1 Panel network over Ethernet 26
7.2 Panel network over CAN 26
7.3 Connect services to panel 27
7.4 Panel network over Ethernet with redundant panels 27
7.5 Panel network over CAN with redundant panels 28
7.6 Panel network over two Ethernet loops 28
7.7 Panel network over two Ethernet loops with redundant panels 28
7.8 Connect Ethernet and CAN network with redundant panels 29
7.9 Connect remote services to redundant panels 29
8
Remote Services 29
8.1 Remote Connect 30
8.2 Remote Alert 32
8.3 Remote Maintenance 32
8.4 Remote Portal 34
9
Voice alarm systems 36
10
Installation 37
10.1 Settings on media converter 38
10.2 Installing Ethernet switch 39
10.3 Settings on switch 39
10.3.1 Assign IP address 40
10.3.2 Program redundancy settings 40
10.3.3 Programming the fault relay 41
10.3.4 Programming connection monitoring 41
10.3.5 QoS priority, only for UGM‑2040 42
10.3.6 Activating IGMP snooping 42

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
