Modular fire panel Remote Services | en 31
Bosch Sicherheitssysteme GmbH Networking guide 07.2019 | 5.9 | F.01U.247.450
To prevent sending EN 54-2 relevant multicast traffic to the router, use the Ethernet switch (in
general MM, BPA-ESWEX-RSR20) approved with panel version 2.8. Activate IGMP snooping of
the Ethernet switch, see the corresponding section in the Installation chapter of the
Networking guide.
Notice!
The internet router (or the company network which provides internet access) as well as the
Secure network gateway must provide separated sub-networks. Panels of the panel network
may not be placed in the sub-network of the internet router. Also overlapping of the sub-
networks is not possible.
In case of overlapping sub-networks you have to separate the sub-networks by changing the
IP addresses on panel network side.
Additionally you have to propagate the changes to the Secure network gateway. To do so,
launch the web interface via a web browser:
- Address: https://192.168.1.254
- User name: bosch
- Password: ipti83
Under Configuration -> Network (LAN) you can change the IP address. Consider, that the
Default gateway: address in the panel controller configuration must match the IP address of
the Secure network gateway.
Notice!
In accordance with DIBt guidelines, remote resetting is not permitted via Remote Services to
restore the operational readiness of door control systems with motorized opening assistance.
The following topology shows a CAN network where a Secure network gateway is connected
to the network via Ethernet port.
Figure8.2: Remote Connect in a CAN loop
