Section 3
Mastering Tool Kit Parameter Functions
The Mastering Tool Kit's algorithms are composed from the following effects.
Equalizer
Bass Cut Filter
Enhancer
Input
Expander
Compressor
Mixer
Limiter
Output
On/Off OFF, ON
This parameter turns the equalizer effect on/off.
Input Gain -24 – +12 dB
Sets the overall volume before passing through the
equalizer.
Low Type SHELVG, PEAK
Sets the equalizer type (shelving, peaking) for the lower
range.
Low Gain -12 – +12 dB
Sets the amount of boost or cut in the lower range.
Low Freq 20 Hz – 2.0 kHz
Sets the center frequency for the lower range.
Low Q 0.3 – 16.0
Sets the steepness of the frequency response curve for the
lower range’s center frequency. (*1)
Low Mid Gain -12 – +12 dB
Sets the amount of boost or cut in the mid-low range.
Low Mid Freq 20 Hz – 8.0 kHz
Sets the center frequency for the mid-low range.
Low Mid Q 0.3 – 16.0
Sets the steepness of the frequency response curve for the
mid-low range’s center frequency.
High Mid Gain -12 – +12 dB
Sets the amount of boost or cut in the upper-low range.
High Mid Freq 20 Hz – 8.0 kHz
Sets the center frequency for the upper-midrange.
High Mid Q 0.3 – 16.0
Sets the steepness of the frequency response curve for the
upper-low range’s center frequency.
High Type SHELVG, PEAK
Sets the equalizer type (shelving, peaking) for the upper
range.
High Gain -12 – +12 dB
Sets the amount of boost or cut in the upper range.
High Freq 1.4 – 20.0 kHz
Sets the center frequency for the upper range.
High Q 0.3 – 16.0
Sets the frequency response curve steepness for the upper
range’s center frequency. (*1)
Output Gain -24 – +12 dB
Sets the overall volume level after equalization.
(*1)The Low Q/Hi Q setting is disabled when “SHELVG”
(shelving type equalization) is selected for the Low
Type or High Type.
Algorithm
=[
EQ
]=[
BCUT
]=[
ENH
]=[
IN
]=[
EXP
]
[
COMP
]=[
MIX
]=[
LIM
]=[
OUT
]
Parameter List
Equalizer
