Connecting Peripheral Devices

Make connections as shown in the diagram below. When making any connections, make sure that all devices are turned off.

fig.00-110

Front Panel

Rear Panel

CD Player etc.

Foot Switch

(FS-5U etc.)

Electric Guitar

Electric Bass

Audio Set etc.

Mic

Expression Pedal

(Roland EV-5 etc.)

AC Adaptor

(PSA series)

Stereo Headphone

Computer
