56 System User Guide Rev. 2.5 Kolibri Ver. 2.0
Operating
How to Connect
Potential
Equalization Cable
Before using the system, connect potential equalization.
How to Connect
Power Supply
Cable
Check voltage setting before plugging power cable into wall outlet.
Steps
1. Plug potential equalization cable
f into potential equalization port j of workstation.
2. Connect potential equalization cable s to potential equalization port g of cart.
3. Plug potential equalization cable
s into an equivalent wall outlet.
Steps
1. Connect power supply cable
d to power inlet k.
2. Connect power supply cable
a to power inlet h.
3. Plug power supply cable
a into wall outlet.
To Next Page
