Brainlab KOLIBRI - Docking & Undocking; Release Pedal

System User Guide Rev. 2.5 Kolibri Ver. 2.0 81
MOBILE CAMERA STAND & CAMERA
5.5.2 Docking & Undocking
Illustration
Figure 43
Figure 44
No. Component
a
Camera arm
s
Camera, example
d
Brakes
f
Locking mechanism (snapped in)
g
Release pedal
a
s
d
f g
