Brainlab KOLIBRI - Sterilizable Camera Handle Sleeve

System User Guide Rev. 2.5 Kolibri Ver. 2.0 71
MOBILE CAMERA STAND & CAMERA
5.4.3 Sterilizable Camera Handle Sleeve
Purpose The sterilizable camera handle sleeve is placed on the camera handle to enable intraoperative cam-
era positioning without compromising the sterile field.
Illustration
Figure 33
How to Place/
Remove
Verify that Camera Handle Sleeve has snapped in properly and cannot be released
without pushing release button.
Sterility
All camera parts are unsterile. Sterilize the sterilizable Camera Handle Sleeve prior to
use as described in
Brainlab Cleaning, Disinfection & Sterilization Guide .
a
s
d
Options
To place the camera handle sleeve
s, slide it over camera handle a until it snaps in properly.
To remove the camera handle sleeve s from camera handle a, push release button d, and
pull camera handle sleeve off.
