MOBILE CAMERA STAND & CAMERA
5.6 Dismantling & Assembling
5.6.1 Applicability
Introduction The camera stand is assembled by Brainlab support.
The Kolibri navigation system supports three camera interfaces. Depending on the camera inter-
face of your camera stand, dismantling and assembling may be supported.
Kolibri Camera
Interface
Figure 46
Kolibri Spectra
Camera Interfaces
Figure 47
Dismantling
Supported
Do not dismantle a camera stand that has a Kolibri Spectra Camera interface with allen
key screws.
a
s d
No. Camera Interface
Dismantling
supported
a
Kolibri Camera interface Yes
s
Kolibri Spectra Camera interface with thumb screws Yes
d
Kolibri Spectra Camera interface with allen key screws No
