MOBILE CAMERA STAND & CAMERA
How to Assemble
Securely tighten knurled screw.
Ensure that button s is locked and that components have been properly attached to
each other.
Steps
1. Put lower part
d in opening f.
2. Tighten knurled screw
g.
3. Unlock button s by pulling it and turning it to the left.
4. Put upper part a into lower part d and lock button s by turning it to the right.
To Next Page
