Blade Description Height Width Thickness Weight
FCOE10-24 FCoE
blade
24-port Brocade port
blade to provide FCoE
support.
41.2 cm
16.2 inches
27.9 cm
11.0 inches
3.6 cm
1.4 in
3.72 kg
8.20 lb
FX8-24 extension
blade (without media)
Enables FCIP
functionality over
existing IP
infrastructure. Has 12
FC ports, 10 1-GbE
ports, and two 10-
GbE ports.
42.1 cm
16.6 inches
29.9 cm
11.8 inches
3.6 cm
1.4 inches
4.20 kg
9.20 lb
FS8-18 Enables data
cryptographic
(encryption/
decryption) and data-
compression for data-
at-rest. Has 16 Fibre
Channel SFP ports.
41.11 cm
16.19 inches
27.98 cm
11.02 inches
3.6 cm
1.4 inches
5.5 kg
12.00 lbs
FRU Description Weight
Port card ller panel Used when a port card is not replaced by another. 1.50 kg
3.20 lb
Power supply Redundant +48 VDC power distribution system with a provision for up to
two 2000-watt, 48 VDC bulk power supplies.
2.45 kg
5.40 lb
Blower assembly Two operating blower assemblies ensure continuous cooling of the
system.
5.73 kg
12.60 lb
WWN card bezel Logo plate containing the two WWN cards beneath. 0.30 kg
0.60 lb
Cable management device Brocade DCX 8510-4: Two vertical cable management nger
assemblies.
Brocade DCX 8510-8: One cable management comb.
0.45 kg
1.00 lb
Chassis door Chassis door for improved cable management. 2.09 kg
4.60 lb
Environmental requirements
Condition Operational Non-operational
Ambient temperature 0°C to 40°C (32°F to 104°F) -25°C to 70°C (-13°F to 158°F)
Relative humidity (non-
condensing)
5% to 93% at 40°C (104°F) with maximum gradient of
10% per hour
10% to 93% at 70°C (158°F)
Altitude (above sea level) 0 to 3000 m (10,000 feet) 0 to 12000 m (40,000 feet)
Shock 20 G, 6 ms, half-sine wave 33 G, 11 ms, half-sine wave
Vibration 0.5 G sine, 0.4 gms random, 5-500 Hz 2.0 G sine, 1.1 gms random, 5-500 Hz
Airow Maximum: 90.1 cmh (53 cfm)
Nominal: 59.5 cmh (35 cfm)
N/A
Heat dissipation Brocade DCX 8510-4: 4078 BTU/hr
Brocade DCX 8510-8: 7654 BTU/hr
N/A
Environmental requirements
Brocade DCX 8510-8 Backbone Hardware Installation Guide
53-1002180-15 181
