Hardware specifications for Brocade MLXe routers
9
• DC Operating Range: -40 to -60V
- Inrush current <70A peak for any initial current surge or spike of 10mS or less at either
cold or warm start.
NOTE
3000W power supplies do not support low line frequencies.
Table 52 lists power consumption, in watts, for Brocade MLXe router components.
TABLE 52 Maximum power consumption for Brocade MLXe router components
Component Maximum power
consumption, in watts
Management modules
MR Management modules (MLXe-4, 8, and 16 routers) 30W
MR Management module (MLXe-32 routers) 35W
MR2 management module (BR-MLX-32-MR2-M for MLXe routers) 45W
MR2 management module (BR-MLX-MR2-M for MLXe routers) 40W
Switch fabric modules
NI-X-SF3 switch fabric module 53W
NI-X-SF1 switch fabric module 19W
NI-X-32-SF switch fabric module 60W
High speed switch fabric modules
NI-X-4-HSF switch fabric module (MLXe-4 routers) 19W
NI-X-16-8-HSF switch fabric module (MLXe-8 and MLXe-16 routers) 53W
NI-X-32-HSF switch fabric module (MLXe-32 routers) 60W
POS interface modules
1-port POS OC192 125W
2-port POS OC192 220W
2-port POS OC48 115W
4-port POS OC48 132W
8-port POS OC48 230W
Interface modules
1-port 100 Gbps Ethernet interface module 485W
2-port 100 Gbps Ethernet interface module 640W
2-port 10 Gbps Ethernet interface module (XMR routers)
2-port 10 Gbps Ethernet interface module with fiber-optic transceivers (MLXe
routers)
150W
4-port 10 Gbps Ethernet interface module with fiber-optic transceivers (MLXe
routers)
225W
8-port 10 Gbps SFPP module (M) 246W
8-port 10 Gbps SFPP interface module (D) 246W
8-port 10 Gbps interface module (X) 270W
