382 Brocade MLX Series and Brocade NetIron XMR Hardware Installation Guide
53-1002373-02
Hardware specifications for Brocade MLXe routers
9
Physical dimensions
Table 54 provides the physical dimensions for Brocade MLXe routers.
Operating environment
Table 55 provides the operating environment specifications for Brocade MLXe routers.
Storage environment
Table 56 provides the storage environment specifications for the Brocade MLXe routers.
Safety agency approvals
• CAN/CSA-C22.2 No. 60950-1-07/UL60950-1 – Second Edition, Safety of Information
Technology Equipment
• EN 60825-1 Safety of Laser Products – Part 1: Equipment Classification, Requirements and
User’s Guide
• EN 60825-2 Safety of Laser Products – Part 2: Safety of Optical Fibre Communications
Systems
• EN 60950-1:2006\IEC 60950-1:2005, Second Edition, Safety of Information Technology
Equipment
Electromagnetic approvals
• FCC Part 15, Subpart B (Class A)
• EN 55022 (CE mark) (Class A)
TABLE 54 Brocade MLXe physical dimensions
Router model Height Width Depth Depth with
Fan FRU
Weight
(empty)
Weight
(fully loaded)
Brocade MLXe-4 22.13 cm
(8.714 in.)
43.69 cm
(17.20 in.)
58.42 cm
(23.0 in.)
63.5 cm
(25.0 in.)
27.40 kg
(60.4 lbs)
52.84 kg
(116.5 lbs.)
Brocade MLXe-8 31.01 cm
(12.21 in.)
43.69 cm
(17.20 in.)
60.96 cm
(24.0 in.)
66.04 cm
(26.0 in.)
35.47 kg
(78.2 lbs.)
77.72 kg
(171.35 lbs.)
Brocade MLXe-16 62.15 cm
(24.47 in.)
44.32 cm
(17.45 in.)
64.77 cm
(24.18 in.)
66.50 cm
(26.18 in.)
41.66 kg
(91.95 lbs.)
159.39 kg
(351.4 lbs)
Brocade MLXe-32 146.58 cm
(57.71 in.)
44.32 cm
(17.45 in.)
61.21 cm
(26.9 in.)
68.58 cm
(27.0 in.)
128.68 kg
(283.7 lbs.)
228.97 kg
(504.8 lbs)
TABLE 55 Brocade MLXe router operating environment
Operating temperature Relative humidity Operating altitude
(0° – 40°C) 32° – 104°F 5 to 90%, at (40°C) 104°F, non-condensing (0 – 2012 meters) 0 – 6600 ft
TABLE 56 Brocade MLXe router storage environment
Storage temperature Storage humidity Storage altitude
(-25° – 70°C) -13° – 158°F 95% maximum relative humidity,
non-condensing
(0 – 4500 meters) 0 – 15,000 ft
