Hardware specifications for Brocade MLXe routers
9
Table 53 lists power consumption information for Brocade MLXe routers with all base components
installed, and with only the specified interface modules installed.
20-port Gbps Ethernet fiber Interface with fiber-optic transceivers (MLX routers) 175W
20-port Gbps Ethernet copper Interface module 146W
24-port 1 Gbps Ethernet copper RJ45 interface module 160W
24-port 1 Gbps Ethernet fiber interface module 160W
48-port Gbps Ethernet with MRJ-21 interface 260W
TABLE 53 Brocade MLXe router power consumption values
Model @100 VAC @200 VAC @-48VDC
Amps Watts BTU/hr Amps Watts BTU/hr Amps Watts BTU/hr
MLXe routers with 8x10G interface modules only
MLXe-4 17 1706 5824 9 1706 5824 36 1706 5824
MLXe-8 33 3332 11372 17 3332 11372 69 3332 11372
MLXe-16 57 5674 19365 28 5674 19365 118 5674 19365
MLXe-32 N/A N/A N/A 57 11391 38876 237 11391 38876
MLXe routers with48-T-A interface modules only
MLXe-4 18 1773 6052 9 1773 6052 37 1773 6052
MLXe-8 35 3465 11827 17 3465 11827 72 3465 11827
MLXe-16 59 5940 20275 30 5940 20275 124 5940 20275
MLXe-32 N/A N/A N/A 60 11924 40696 248 11924 40696
MLXe routers with legacy MLX interface modules only
MLXe-4 16 1630 5564 8 1630 5564 34 1630 5564
MLXe-8 32 5180 10852 16 3180 10852 66 3180 10852
MLXe-16 54 5369 18325 27 5369 18325 112 5369 18325
MLXe-32 N/A N/A N/A 54 10781 36797 225 10781 36797
MLXe routers with XMR interface modules only
MLXe-4 17 1702 5808 9 1702 5808 35 1702 5808
MLXe-8 33 3322 11340 17 3322 11340 69 3322 11340
MLXe-16 57 5655 19300 28 5655 19300 118 5655 19300
MLXe-32 N/A N/A N/A 57 11353 38746 237 11353 38746
TABLE 52 Maximum power consumption for Brocade MLXe router components (Continued)
Component Maximum power
consumption, in watts
