Brocade Communications Systems MLX Series User Manual

284 Brocade MLX Series and NetIron XMR Hardware Installation Guide
53-1002373-02
Installing a Brocade NetIron XMR 32000 router
4
Cable routing for the upper-right quadrant
Route cables from slots in numerical order starting with the cables for slot #15.
1. Route cables from slots #15 and #16 directly to the right through the side comb. Refer to
Figure 198.
FIGURE 198 Routing Upper-right quadrant cables to the right
1 Upper right quadrant 3 Cables from slot #15
2 Side combs (18) 4 Cables from slot #16
2
1
3
4
