Installing a Brocade NetIron XMR 32000 router
4
FIGURE 197 Routing upper-left quadrant cables up
2. Route cables from slots #3 and #4 up through comb A. Refer to Figure 197.
3. Route cables from slots #5 and #6 up through comb B.
4. Route cables from slots #7 and #8 up through comb C.
1 Upper left quadrant 3 Comb B (slot #5 and #6 cables)
2 Comb C (slot #7 and #8 cables) 4 Comb A (slot #3 and #4 cables)
1
2
3
4
