384 Brocade MLX Series and Brocade NetIron XMR Hardware Installation Guide
53-1002373-02
Hardware specifications for Brocade MLX routers
9
Hardware specifications for Brocade MLX routers
The following sections describe hardware specifications for Brocade MLX routers.
Power specifications
The following power supply frequency requirements apply to Brocade MLX 4-slot, 8-slot, and 16-slot
routers:
• AC Input Rating: 100 to 240V, 50/60 Hz, 16.0 A maximum per power supply
• AC Operating Voltage Range: 90 - 264V, 50/60 Hz
• Inrush current: 40A peak maximum at 25 degrees C (77 degrees F)
• DC Input Rating: -48V, 30.0 A maximum per power supply
• DC Operating Range: -40 to -60V
• Inrush current: 45A peak maximum at 25 degrees C (77 degrees F)
The following power supply frequency requirements apply to the Brocade MLX-32 routers:
• AC Input Rating: 200 -240V, 50/60 Hz, 16.0 A maximum per power supply
• AC Operating Voltage Range: 180 to 264V
• Inrush current: 30A peak maximum at 25 degrees C (77 degrees F)
• DC Input Rating: -48V, 60.0 A maximum per power supply
• DC Operating Range: -40 to -60V
• Inrush current: 45A peak maximum at 25 degrees C (77 degrees F)
Table 57 lists power consumption information for Brocade MLX routers with all base components
installed, and with only the specified interface modules installed.
TABLE 57 Brocade MLX router power consumption values
Model @100 VAC @200 VAC @-48VDC
Amps Watts BTU/hr Amps Watts BTU/hr Amps Watts BTU/hr
MLX routers with 8x10G interface modules only
MLX-4 14 1389 4740 7 1389 4740 29 1389 4740
MLX-8 28 2760 9419 14 2760 9419 57 2760 9419
MLX-16 56 5591 19081 28 5591 19081 116 5591 19081
MLX-32 N/A N/A N/A 57 11391 38876 237 11391 38876
MLX routers with48-T-A interface modules only
MLX-4 15 1445 4967 7 1455 4967 30 1435 4967
MLX-8 29 2893 9873 14 2893 9873 60 2893 9873
MLX-16 59 5857 19991 29 5857 19991 122 5857 19991
MLX-32 N/A N/A N/A 60 11924 40696 248 11924 40696
MLX routers with legacy MLX interface modules only
MLX-4 13 1313 4480 7 1313 4480 27 1313 4480
MLX-8 26 2607 8899 13 2607 8899 54 2607 8899
