Hardware specifications for Brocade MLX routers
9
Table 58 lists power consumption values for Brocade MLX router components.
Inter
MLX-16 53 5286 18041 26 5286 18041 110 5286 18041
MLX-32 N/A N/A N/A 54 10781 36797 225 10781 36797
TABLE 58 Maximum power consumption for Brocade MLX router components
Component Maximum power
consumption, in watts
Management Modules
MR management module (Brocade MLX 4-slot, 8-slot and 16-slot routers) 30W
MR management module (Brocade MLX 32-slot routers) 35W
MR2 management module (BR-MLX-MR2-M for Brocade MLX 4-slot, 8-slot, and 16-slot
routers)
40W
MR2 management module (BR-MLx-32-MR2-M for Brocade MLX 32-slot routers) 45W
Switch Fabric Modules
NI-X-SF1 4-slot switch fabric module (Brocade MLX 4-slot, 8-slot and 16-slot routers) 19W
NI-X-SF3 8/16-slot switch fabric module (Brocade MLX 4-slot, 8-slot and 16-slot routers) 53W
NI-X-32-SF 32-slot switch fabric module (Brocade MLX 32-slot routers) 60W
High-speed switch fabric modules
NI-X-4-HSF 19W
NI-X-16-8-HSF 53W
NI-X-32-HSF 60W
POS interface modules
1-port POS OC192 125W
2-port POS OC192 220W
2-port POS OC48 115W
4-port POS OC48 132W
8-port POS OC48 230W
Interface modules
1-port 100 Gbps Ethernet interface module 485W
2-port 10 Gbps Ethernet interface module with fiber-optic transceivers 150W
4-port 10 Gbps Ethernet interface module with fiber-optic transceivers 225W
8-port 10 Gbps Gen 2 Ethernet interface module (M) 246W
4-port 10 Gbps Ethernet interface module (X) 240W
8-port 10 Gbps Ethernet interface module (D) 246W
20-port Gbps Ethernet fiber Interface with fiber-optic transceivers 175W
TABLE 57 Brocade MLX router power consumption values (Continued)
Model @100 VAC @200 VAC @-48VDC
Amps Watts BTU/hr Amps Watts BTU/hr Amps Watts BTU/hr
