Brocade Communications Systems MLX Series User Manual

Brocade MLX Series and Brocade NetIron XMR Hardware Installation Guide 303
53-1002373-02
Chapter
5
Using Brocade Structured Cabling Components
Cable cinch overview
Position the cable cinch with the open end to the left (no slot) as shown in Figure 211.
FIGURE 211 Cable cinch overview
mRJ21 procedures
The following procedure demonstrates securing up to eight mRJ21 cables into the cable cinch.
When securing fewer than the maximum cables, follow the procedure to secure the desired
number of cables and simply wrap the remaining Velcro strap around the cable cinch. Use the
additional slots in the clip to secure groups of cables as required.
1 Slot 1 5 Open end
2Slot 2 6Rear
3Slot 3 7Front
4Slot 4
123
45
6
7
