Brookfield DV3T User Manual

Brookeld Engineering Labs., Inc. Page 10 Manual No. M13-167-A0415
7. MakesurethattheACpowerswitchattherearoftheDV3TisintheOFFposition.
Connectthepowercordtothesocketonthebackpaneloftheinstrumentandplugitinto
theappropriateACline.ForCone/PlateModels,besurethatthetoggleswitch,usedto
activatetheelectronicgap,istotheleftposition.(Leftwhenfacingtherheometer.)
TheACinputvoltageandfrequencymustbewithintheappropriaterangeas
shownonthenameplateoftherheometer.(SeeSectionI.2.)
Note: TheDV3Tmustbeearthgroundedtoensureagainstelectronicfailure!!
8. TurnthepowerswitchtotheONpositionandallowtherheometertowarmupfor10
minutesbeforeperformingautozero.
9. ForCone/Platemodels,refertoAppendixA.
10. Ifappropriate,connectUSBcable(DVP-202)toUSBportforconnectionofDV3T
toPCorprinter.
11. ReviewReadMele.TheReadMelecontainsnotesontheDV2TFirmware.Thisle
canbefoundontheCDthatcontainsthePGFlashSoftware.
Temperature
Probe
USB B
USB A
On/Off
Switch
Ethernet
(Future Use)
Power Input
Temperature
Controller
Figure I-2
