Appendix K - Screen Protector

TheBrookeldDV3TRheometerisprovidedwithascreenprotectorthatcanbeappliedtothe

touchscreensurface.Thisscreenprotectorisdesignedforprolongeduse.Brookeldrecommends

replacingthescreenprotectorwithin1yearofapplication.Thescreenprotectorisprovidedina

kit(partnumberGV-1019)thatincludesthefollowingitems:

• Twoscreenprotectors(withmountedapplicatorandtabs)

• Onescreencloth(partnumberGV-1045)

• Onesoftcard

• Instructionsprintedonthepackage

Retainthesoftcardandscreenclothwithanyunusedscreenprotector.

Install the Screen Protector

Installationinstructionsforthescreenprotectorareavailableinthreemethods:

1. Readprintedinstructionsonthepackage

2. ViewtheinstructionalvideoontheBrookeldYouTubeChannel:

  www.youtube.com/user/BrookeldEng

3. Readtheexpandedprintedinstructionsinthisappendix(seebelow).

A failure to properly install the screen protector may result in a disabled

touch screen.

Step1:

• TurnofftheDV3Trheometer(powerdown)priortoinstallation.

• Clean the DV3T touch screen with the screen cloth prior to

installation. Any debris, dust, or oil on the touch screen may

preventproperadhesionofthescreenprotector.

• IdentifyTab1andTab2priortoremovinganyprotectivelayer.

PeelbackadhesiveTab1,fromthebottom,toexposehalfofthe

protector(seeFigureK-1).

• Donottouchtheexposedsurfaceoftheadhesivesideofthescreen

protector.

Step2:

• Alignmentofthescreenprotectortothebezel(frame)oftheDV3T

iscritical.Besuretoavoidmis-alignmentwhichmayresultinthe

screenprotectorcontactingorlocatingunderthebezel(frame).

Afoamalignmenttoolisattachedtothescreenprotector’souter

layerandshouldbeusedtolocatethescreenprotectortothelower

righthandcornerofthetouchscreen(seeFigureK-2).

Failure to properly align (install) the screen protector could result in a

failure of the touch screen.

Figure K-1

Figure K-2
