Brookeld Engineering Labs., Inc. Page 8 Manual No. M13-167-A0415

I.2 Utilities

InputVoltage: UniversalPowerSupply(90-264VAC)

InputFrequency: 50/60Hz

PowerConsumption: 150VA

PowerCordColorCode:

United States Outside United States

Hot(live) Black Brown

Neutral White Blue

Ground(earth) Green Green/Yellow

Mainsupplyvoltageuctuationsarenottoexceed±10%ofthenominalsupply

voltage.

 I.3 Specications

Speeds: 0.01 - 250 RPM

Weight:

 GrossWeight 23 lbs. 10.5kg.

 NetWeight 20 lbs. 9kg.

 CartonVolume 1.65 cu.ft. 0.05m

 CartonDimensions22in.(56cm)Wx11in.(28cm)Lx22in.(56cm)H

Temperature Sensing Range: -100˚Cto300˚C(-148˚Fto572˚F)

USB A Port for use with an attached PC.

USB B Port (x3) for use with a USB Flash Drive and Dymo Printer.

Viscosity Accuracy:

 ±1.0%offullscalerange

 Theuseofaccessoryitemswillhaveaneffectonthe 

 measurementaccuracy.SeeAppendixB.

Viscosity Repeatability: ±0.2%ofFullScaleRange

Temperature Accuracy: ±1°C|-100°Cto+149°C

 ±2°C|+150°Cto+300°C

Operating Environment: 0°Cto40°Ctemperaturerange(32°Fto104°F)

 20%-80%R.H.:non-condensingatmosphere

Ball Bearing Option:

Ifyouorderedtheballbearingsuspensionsystemwithyournewinstrument,pleasenote

thefollowing:

1) TheballbearingsuspensioninyourBrookeldinstrumentisnotedontheserialtagon

thebackoftheheadbytheletter“B”inthepartnumber(theninthdigit;forexample:

XDV3THBTB00U00.

2) Whenattachinganddetachingthespindle,itisnotnecessarytoliftthecouplingwhere

thespindleconnectstotheinstrument.

3) TheOscillationCheck,explainedinSectionIV.1:DeviceSetup,doesnotpertainto

thisinstrument.
